Electric Cast Globe Valve / Stainless Steel Globe Valve Customized Size

Electric Cast Globe Valve / Stainless Steel Globe Valve Customized Size
Electric Cast Globe Valve / Stainless Steel Globe Valve Customized Size

Large Image :  Electric Cast Globe Valve / Stainless Steel Globe Valve Customized Size

Product Details:
Place of Origin: China
Brand Name: Kelite Valve
Certification: API, ISO, CE, GOST, TS, BS1873, BS5351, API 6D,600,602,609, ASME B16.34, API 6FA, API607 etc
Model Number: 2"-24", CL150-1500
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Packaging Details: Plywood packing or fumigation packing
Delivery Time: 30-60days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000-5000PCS per month
Contact Now
Detailed Product Description
Size：: NPS 2"~24" Pressure Rating：: Class 150~1500
Material：: CF8M, CF3,CF3M, CN7M, CF8CWCB, LCB, WC6, WC9, C12, C5, CF8, CF8M, CF3, CF3M Design & Manufacturing Standard：: BS 1873 ,ASME B16.34, API 600
Face To Face：: ASME B16.10 Flanged Dimenson：: ASME B16.5, ASME B16.47, BSEN 1092
End Connection：: ASME B16.25BSEN 558, ASME B16.5 ,BSEN 1092 Operation Method：: Manual ,Worm Gear, Electric Actuator, Pneumatic Actuator
High Light:

cast steel globe valve

,

rising stem globe valve

2"-24" CL150-1500 bolted bonnet cast globe valve, OS&Y, rising stem



Size: NPS 2"~24"
Pressure Rating: Class 150~1500
Material: CF8M, CF3,CF3M, CN7M, CF8CWCB, LCB, WC6, WC9, C12, C5, CF8, CF8M, CF3, CF3M
Design & Manufacturing Standard: BS 1873 ,ASME B16.34
Face to Face: ASME B16.10
Flanged Dimenson: ASME B16.5, ASME B16.47, BSEN 1092
End Connection: ASME B16.25BSEN 558, ASME B16.5 ,BSEN 1092
Test and Inspection: ISO 5208,BS 6755
Structure type: Straight type, angle type, throttle type
Operation Method: Manual ,Worm Gear, Electric Actuator,
Pneumatic Actuator





Design

Kelite cast steel globe valves are designed and manufactured to provide maximum service life and dependability. All globe valve are full ported and meet the design requirements of American Petroleum Institute standard API600& 6D.BS EN 13709 and generally conform to American Society of Mechanical Engineers standard ASME B16.34 .Valves are available in a complete range of body/bonnet materials and trims.

Ranges of Materials

Standard body/bonnet materials include nine grades of carbon, low alloy and stainless steel, for special applications they can be supplied in other grades of alloy and stainless steel, there’s a full range of trim materials to match any service optional packing and gasket materials are available for a full range of service conditions.



Available Modifications For Kelite Steel Valves

Trim changes
End connection modifications
Packing and gasket changes
Operator mounting
Handwheel extensions		 Pressure equalizing
By-pass
Customer specified coatings
Weld end bore changes
Oxygen & chlorine cleaning & packaging



Electric Cast Globe Valve / Stainless Steel Globe Valve Customized Size 0

Tag:

bellow sealed valve,

globe valve,

bellow sealed
