3 Piece Floating Type Ball Valve , Flanged Ball Valve Soft - Seated Feature

Large Image : 3 Piece Floating Type Ball Valve , Flanged Ball Valve Soft - Seated Feature

Product Details:

Place of Origin:	China
Brand Name:	Kelite Valve
Certification:	API, ISO, CE, GOST, TS, BS1873, BS5351, API 6D,600,602,609, ASME B16.34, API 6FA, API607 etc
Model Number:	1/2"-2", CL150-2500

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Packaging Details:	Plywood packing or fumigation packing
Delivery Time:	30-60days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	3000-5000PCS per month

Contact Now

Detailed Product Description

Size::	NPS 1/2"~2"	Pressure Rating::	Class 150~2500
Material::	WCB, LCB, CF8, CF8M, CF3,CF3M	Design Standard::	API 608, API 6D, BS 5351, ASME B16.34
Face To Face::	ASME B16.10, API 6D, BSEN 558	End Connection::	ASME B16.5, BSEN 1092
High Light:	float operated ball valve , stainless steel ball float valve

3 piece forged floating type ball valve of 1/2"-8" CL150-600 API 6D , 608 desgin

PRODUCT RANGE

Class 800 from ½'' to 2''
Class 1500 from ½'' to 2''

Class 2500 from 1/2" to 2"

MATERIALS

BODY: Carbon steel, Stainless steel, Low temperature carbon steel, Duplex, Special Alloys,... Other materials under request
SOFT SEATS : PTFE, RPTFE, PEEK, DEVLON, NYLON,... Other materials under request
METAL SEAT:Tungsten Carbide(TC), Stellited
, Ni60...Other materials under request.

TRIM: A105+EP,304,316, 410, MONEL,... Other materials under request

DESIGN STANDARDS

ASME Standards:
B1.20.1	Pipe Threads,General Purpose(Inch)
B16.10	Face-to-Face and End-to-End Dimensions of Valves
B16.25	Buttwelding Ends
B16.11	Forged Fittings, Socket-Welding and Threaded
B16.5	Flanged Fittings and Pipe Flanges
B16.47	Large Diameter Steel Flanges
API Standards:
6D	Specifications for Pipeline valves
598	Valve Inspection and Testing
607	Fire test for soft-seated quarter-turn valves
6FA	Specification for Fire Test for Valves
MSS Standards:
SP-55	Quality Standard for Steel Castings for Valves,Flanges,and Fittings and Other Piping Components-Visual Method for Evaluation of Surface Irregularities
SP-54	Quality Standard for Steel Castings for Valves,Flanges,and Fittings and Other Piping Components-Radiographic Examination Method
SP-53	Quality Standard for Steel Castings for Valves,Flanges,and Fittings and Other Piping Components-Magnetic Particle Examination Method

DESIGN FEATURE

Split body, full bore. Fire-Safe certified, floating ball, blow out proof stem, flanged connections.
Non-removable antistatic devices assure electric continuity between ball and body through the stem.
All wetted component materials and bolting meet NACE MR.01.75 latest edition as standard.
Cavity pressure relief hole avoids overpressure in the cavity with the valve in open position.
Asbestos free.

APPLICATION

Refinery
Chemical
Petrochemical
Power plant
Gas

3 Piece Floating Type Ball Valve , Flanged Ball Valve Soft - Seated Feature 0
