Rising Stem Cast Globe Valve Screwed End DN8 - DN65 High Efficiency API Certification

China Rising Stem Cast Globe Valve Screwed End DN8 - DN65 High Efficiency API Certification supplier

Large Image :  Rising Stem Cast Globe Valve Screwed End DN8 - DN65 High Efficiency API Certification

Product Details:

Place of Origin: China
Brand Name: Kelite Valve
Certification: ISO, CE,API
Model Number: 1/4"~2-1/2",

Payment & Shipping Terms:

Minimum Order Quantity: 1PC
Packaging Details: Plywood packing or fumigation packing
Delivery Time: 10-80days
Supply Ability: 3000-8000PCS per month
Contact Now
Detailed Product Description
Size: 1/4"~2-1/2" Pressure: W. P.: 200 WOG
Material: Steel Certifcate: CE, API,ISO
Operation: Lever


GLOBE VALVE SCREWED END

Specifications:

  1. 1/4"~2-1/2" (DN8~DN65)
  2. W. P.: 200 WOG
  3. W. T.:-20℃ ~200℃ (-4℉~392℉)
  4. Investment casting
  5. Rising stem
  6. Thread type: ASME B1.20.1 (NPT)
    DIN 2999 & BS21
    ISO7/1 & EN10226





ITEM PARTS MATERIAL
1 BODY ASTM A351-CF8M ASTM A351-CF8
2 BONNET
3 DISC
4 SEAL PTFE
5 WASHER AISI 304
6 PACKING PTFE
7 GLAND RING AISI 304
8 CAP NUT ASTM A351-CF8M ASTM A351-CF8
9 STEM AISI 316 AISI 304
10 HANDLE ALUMINUM
11 NAMEPLATE
12 NUT AISI 304



Screwed End Globe Valve 2028 200WOG - Haitima Valve p2
